Beschrijving

Features

• 370W RGB + Warm White LED source (driven @ 220W)
• CRI > 94; R9 > 88,8; TLCI > 92
• 4 section pixel control and built-in lighting effects for cinema applications
• Silent operation with multiple fan modes
• Battery connection (4pXLR 24-36V): compatible with industry standard external batteries (optional)

Specifications
LIGHT SOURCE

• Source: 370W RGB + Warm White LEDs (driven @ 220W)
• Luminous flux: 17’109lm @4.000 K with LD filter
• Lux: @4000K, 265lx @5 m
• CRI: 90 @3.200 K; 94 @5.600 K
• R9: 84,1 @3.200 K; 88,8 @5.600 K
• TLCI: 92 @5.600 K
• TM30 Rf: 90 @3.200 K; 89,4 @5.600 K
• TM30 Rg: 105 @3.200 K; 104 @5.600 K
• Source life expectancy: > 50.000 h

OPTICS

• Beam angle: 102°
• Field angle: 158°
• Lens type: medium density diffusion panel (interchangeable)
• Additional optics: see available accessories

COLOUR SYSTEM

• Colour mixing: RGB + Warm White
• CCT: CCT control, + / – green correction, tungsten emulation
• White presets: 2.800 K – 10.000K with 28 K resolution
• Colour wheel: virtual colour wheel with macros

DYNAMIC EFFECTS

• Control Resolution: 16bit dimmer, colours
• Pixel patterns: pre-programmed pixel macros and cinema lighting effects patterns
• Special features: linear crossfade channel from any white to any colour; virtual CTO on colours

BODY

• Body: sturdy die-cast aluminium body
• Body colour: black

CONTROL

• Protocols: DMX512, RDM, W-DMX, rotatory knob
• Stand Alone: selectable mode through 3 rotatory knobs
• Pixel control: 4 section control
• W-DMX: included, wireless solution receiver
• RDM: RDM for remote monitoring and settings
• Display: Graphic User Interface
• Firmware upgrade: yes, via USB – DMX interface (UPBOX1) not included

ELECTRONICS

• Dimmer: linear 0 ~ 100% electronic dimmer
• Dimmer curves: selectable dimming modes available
• Strobe / shutter: 1 – 30 Hz, electronic
• Display battery: self-charging battery backup
• Operating temperature: -20° ~ +45°
• LED Control: flicker free frequency with adjustable PWM
• Selectable PWM: 600 ~ 40.000 Hz

ELECTRICAL

• Mains power supply: 100-240V – 50/60Hz
• Low Voltage DC mains: 24-36V
• Max power consumption: 230W
• Power factor: >0,97

PHYSICAL

• IP rating: 20
• Cooling: active, silent operation
• Suspension and fixing: bracket for hanging and positioning
• Signal connection: Amphenol XLR 5p IN/OUT connectors
• Power connection: Neutrik powerCON TRUE1 IN/OUT connectors
• Low Voltage DC connector: XLR 4p
• Dimensions (WxHxD): 529x430x144 mm / (with PO system) 546x430x144mm / 20.83”x16.93”x5.67”
• Weight: 10,5/()11,8kg / 23.15lbs
