Beschrijving
| Digital / Analoog: | Digitaal |
| Input kanalen: | 32 Input kanalen, 8 Aux kanalen, 8 FX Return kanalen |
| Output kanalen: | 16 |
| Lokale inputs: | 8 / 16 |
| Lokale outputs: | 8 / 16 |
| Digitale i/o: | 32 bidirectionele audio I/O kanalen via USB 2.0 |
| Interne effect processoren: | 8 True Stereo / 16 Mono |
| Interne Show Automation (structured Cues / Snippets): | 500 / 100 |
| Interne op te roepen Scenes (incl. Preamplifiers en Faders): | 100 |
| Scherm: | 7″ TFT LCD, 800 x 480 Resolutie, 262k kleur | 128 x 64 LCD with RGB kleuren Backlight | Hoofdmeter: 24 Segment (-57 dB to Clip) |
| Faders: | 17 Midas PRO motor faders |
| Signaal Processie: | 40 bit signal flow |
| Bussen: | 25 time-aligned en phase-coherent mix bussen |
| DCA: | 8 DCA en 6 mute groepen |
| RTA: | 100-band |
| Kaart slot: | DN32-Live (te vervangen) |
| Remote functie: | DAW remote control emulator met Mackie Control* en HUI* protocollen |
| Overige aansluitingen: | |
| – Midas PRO Series Microphone Preamplifier (XLR): | 16 |
| – Talkback Microphone Input (XLR): | 1 |
| – RCA Inputs / Outputs: | 2/2 |
| – Monitoring Outputs (XLR / ¼” TRS Balanced): | 2/2 |
| – Phones Output (¼” TRS): | 1 (Stereo) |
| – AES50 Ports (Klark Teknik SuperMAC): | 2 |
| – ULTRANET P-16 Connector (No Power Supplied): | 1 |
| – MIDI Inputs / Outputs: | 1/1 |
| – USB Type A (Audio and Data Import / Export): | 1 |
| – USB Type B, rear panel, for remote control: | 1 |
| – Ethernet, RJ45, rear panel, for remote control: | 1 |
| Spanning: | Auto-Ranging 100-240 VAC (50/60 Hz) ± 10% | 70 W |
| Afmetingen: | 47.8 x 61.7 x 20.8 cm |
| Gewicht: | 18.1 Kg (39.9 lbs) |
